CLOCKWISE ROTATION
- Direct Interchange for Vickers V20
- Balanced Vane Type
- Fixed Displacement
- Quieter operation than Gear Pump
- High Efficiency
- 100% Tested
- *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.
| Image | Item # | Mfr. Number | Rotation | in3 Per Rev. | GPM @ 1200 RPM | Max. PSI | Max. RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 6303223 | V201P6P62A11 | CW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303224 | V201P7P62A11 | CW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303225 | V201P8P62A11 | CW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303226 | V201P9P62A11 | CW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303227 | V201P10P62A11 | CW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303228 | V201P11P62A11 | CW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303229 | V201P12P62A11 | CW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303230 | V201P13P62A11 | CW | 2.59 | 13 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303231 | V201P6P62B11 | CW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303232 | V201P7P62B11 | CW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303233 | V201P8P62B11 | CW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303234 | V201P9P62B11 | CW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303235 | V201P10P62B11 | CW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303236 | V201P11P62B11 | CW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day | |||
 | 6303237 | V201P12P62B11 | CW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 5/8" 9-Tooth Spline | $277.07 / EACH Ships next business day |
