COUNTERCLOCKWISE ROTATION
- Direct Interchange for Vickers V20
- Balanced Vane Type
- Fixed Displacement
- Quieter operation than Gear Pump
- High Efficiency
- 100% Tested
- *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.

Image | Item # | Mfr. Number | Rotation | in3 Per Rev. | GPM @ 1200 RPM | Max. PSI | Max. RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() | 6303441 | V201P6S1A11L | CCW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303442 | V201P7S1A11L | CCW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303443 | V201P8S1A11L | CCW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303444 | V201P9S1A11L | CCW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303445 | V201P10S1A11L | CCW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303446 | V201P11S1A11L | CCW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303447 | V201P12S1A11L | CCW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303448 | V201P13S1A11L | CCW | 2.59 | 13 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303449 | V201P6S1B11L | CCW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303450 | V201P7S1B11L | CCW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303451 | V201P8S1B11L | CCW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303452 | V201P9S1B11L | CCW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303453 | V201P10S1B11L | CCW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303454 | V201P11S1B11L | CCW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303455 | V201P12S1B11L | CCW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | #12 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day |
