CLOCKWISE ROTATION
- Direct Interchange for Vickers V20
- Balanced Vane Type
- Fixed Displacement
- Clockwise Rotation
- Quieter operation than Gear Pump
- High Efficiency
- 100% Tested
- *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.

Image | Item # | Mfr. Number | Rotation | in3 Per Rev. | GPM @ 1200 RPM | Max. PSI | Max. RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() | 6302284 | V201P6P1A11 | CW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302307 | V201P7P1A11 | CW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302330 | V201P8P1A11 | CW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302353 | V201P9P1A11 | CW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH In stock - Ships same day | |||
![]() | 6302553 | V201P10P1A11 | CW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302376 | V201P11P1A11 | CW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302399 | V201P12P1A11 | CW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302422 | V201P13P1A11 | CW | 2.59 | 13 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303193 | V201P6P1B11 | CW | 1.19 | 6 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303194 | V201P7P1B11 | CW | 1.39 | 7 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302308 | V201P8P1B11 | CW | 1.62 | 8 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $329.84 / EACH Ships next business day | |||
![]() | 6302352 | V201P9P1B11 | CW | 1.81 | 9 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303195 | V201P10P1B11 | CW | 1.93 | 10 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6302212 | V201P11P1B11 | CW | 2.22 | 11 GPM | 2500 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day | |||
![]() | 6303196 | V201P12P1B11 | CW | 2.38 | 12 GPM | 2200 PSI | 1800 RPM | 1-1/4" NPT | 3/4" NPT | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 2-5/8" Length Keyed Shaft | $277.07 / EACH Ships next business day |
