  • Direct Interchange for Vickers V10
  • Balanced Vane Type
  • Fixed Displacement
  • Quieter operation than Gear Pump
  • High Efficiency
  • 100% Tested
  • *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.
*** Slide left / right to view more ***
ImageItem #Mfr. NumberRotationin3 Per Rev.GPM @ 1200 RPMMax. PSIMax. RPMInletOutletPort OrientationShaftPriceOrder Qty.
6302883V101S1S11A20CW0.21 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet Opposite Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303027V101S2S11A20CW0.42 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet Opposite Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303028V101S3S11A20CW0.63 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet Opposite Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303029V101S4S11A20CW0.84 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet Opposite Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303030V101S5S11A20CW15 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet Opposite Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303031V101S6S11A20CW1.196 GPM2200 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet Opposite Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303032V101S7S11A20CW1.397 GPM2000 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet Opposite Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303033V101S1S11B20CW0.21 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet 90 Deg CCW from Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303034V101S2S11B20CW0.42 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet 90 Deg CCW from Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303035V101S3S11B20CW0.63 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet 90 Deg CCW from Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303036V101S4S11B20CW0.84 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet 90 Deg CCW from Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303037V101S5S11B20CW15 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet 90 Deg CCW from Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303038V101S6S11B20CW1.196 GPM2200 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet 90 Deg CCW from Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303039V101S7S11B20CW1.397 GPM2000 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet 90 Deg CCW from Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
6303040V101S1S11C20CW0.21 GPM2500 PSI1800 RPM#16 SAE O-Ring#08 SAE O-RingOutlet In Line with Inlet5/8-9 Splined Shaft $210.53 / EACH
Ships next business day
   Page of 2
