1-1/4" 14 TOOTH SPLINED SHAFT 2.44" LONG - SAE C, VICKERS REPLACEMENT PUMPS
- Low Noise Characteristics
- 10 Vane Systems - Low Amplitude Flow Pulsations
- Long Life
- Inlet and outlet ports can be oriented in four different positions relative to each other
| Image | Item # | Mfr. Number | Rotation | In3 Per Rev. | GPM @ RPM 1200 | Max PSI | Max RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 6301249 | 45V42A11A22R | CW | 8.41 | 42 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet Opposite Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301251 | 45V50A11A22R | CW | 9.85 | 50 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet Opposite Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301252 | 45V60A11A22R | CW | 11.8 | 60 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet Opposite Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301253 | 45V42A11A22L | CCW | 8.41 | 42 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet Opposite Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301255 | 45V50A11A22L | CCW | 9.85 | 50 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet Opposite Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301256 | 45V60A11A22L | CCW | 11.8 | 60 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet Opposite Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301265 | 45V42A11B22R | CW | 8.41 | 42 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet 90 Deg CCW from Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301267 | 45V50A11B22R | CW | 9.85 | 50 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet 90 Deg CCW from Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301268 | 45V60A11B22R | CW | 11.8 | 60 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet 90 Deg CCW from Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301269 | 45V42A11B22L | CCW | 8.41 | 42 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet 90 Deg CCW from Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301271 | 45V50A11B22L | CCW | 9.85 | 50 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet 90 Deg CCW from Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301272 | 45V60A11B22L | CCW | 11.8 | 60 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet 90 Deg CCW from Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301281 | 45V42A11C22R | CW | 8.41 | 42 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet In Line with Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301283 | 45V50A11C22R | CW | 9.85 | 50 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet In Line with Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day | |||
 | 6301284 | 45V60A11C22R | CW | 11.8 | 60 | 2500 | 1800 | #48 code 61 | #24 code 61 | Outlet In Line with Inlet | 1-1/4" - 14 Splined x 2.44" Length Splined Shaft | $967.68 / EACH Ships next business day |
