6301141
25V21A1C22R VICKERS REPLACEMENT, HYDRAULIC PUMP FIXED VANE 4.13 IN3 DISPLACEMENT, MOUNT IS STANDARD SAE-B 2-BOLT FLANGE 7/8" ROUND X 3/16" KEYED X 2.32" LONG SHAFT (INCLUDES PILOT LENGTH), PILOT DIAMETER IS 4.00", 2500 PSI MAXIMUM, 1800 RPM MAXIMUM, CW ROTATION, #24 CODE 61 INLET, #16 CODE 61 OUTLET, OUTLET IN INLINE AND ON THE SAME SIDE AS THE INLET WHEN VIEWED FROM THE COVER END OF THE PUMP, VICKERS REPLACEMENT 25V21A1C22R
| Mfr. Number | Rotation | In3 Per Rev. | GPM @ RPM 1200 | Max PSI | Max RPM | Inlet | Outlet | Port Orientation | Shaft |
|---|---|---|---|---|---|---|---|---|---|
| 25V21A1C22R | CW | 4.1 | 21 | 2500 | 1800 | #24 code 61 | #16 code 61 | Outlet In Line with Inlet | 7/8" Dia x 3/16" Key x 2.32" Length Keyed Shaft |
