  • The GT100 Series vented brass oil gauge has a male elbow base and integral, wetted dial thermometer providing direct reading of the fluid temperature
  • The viewing window has 360° adjustment for optimal orientation to view fluid after installation
  • The sealing gaskets are contained on both their ID and OD to facilitate trouble-free assembly after on-site repositioning of the viewing window
  • 0.88 inch SQ base
  • Male tapered pipe thread base connection (1/4, 3/8, 1/2 or 3/4 inch NPTF)
  • 0.39 inch wide viewing window, length varies from 1.33 to 7.33 inches depending on gauge selected
  • 1.38 inch diameter dual scale dial thermometer, 50°F to 300°F
  • 360° adjustment of viewing window
  • Suitable for use with most machine lubricating oils
  • Brass construction
  • Buna N seals
  • Borosilicate glass sight
  • Maximum operating temperature of 250°F with standard Buna N seals
*** Slide left / right to view more ***
ImageItem #Mfr. NumberThreadsViewing WindowPriceOrder Qty.
1232703GT103-21/4"1.83" x 0.39" $80.26 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 2
1232704GT105-21/4"2.83" x 0.39" $80.83 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 2
1232705GT105-33/8"2.83" x 0.39" $85.22 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 2
1232706GT107-41/2"4.33" x 0.39" $84.40 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 2
1232707GT108-41/2"5.33" x 0.39" $86.64 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 2
1232708GT109-53/4"7.33" x 0.39" $95.81 / EACH
Usually ships in 3 day(s)
MIN ORD QTY: 2
