  • For Use on Either Case Drain or Return Line Flows
  • One, Two, & Three Pass Models Available
  • Mount behind the motor on the power unit using the TEFC fan to move air across the cooler
  • Eliminates the need for an additional cooling fan motor
  • Foot mounting brackets include rubber vibration isolators
  • JIC connections standard
  • More options are available. Please contact us and speak to a sales representative for more information.
*** Slide left / right to view more ***
ImageItem #Nema Motor Frame SizeMaximum GPMHP Removed @ 50°F ΔT2 Nema Motor Frame Size2 Maximum GPM2 HP Removed @ 50°F ΔTLength x Width x DepthPort SizePriceOrder Qty.
749400356 - 14515 GPM0.88 HP---9.8" x 7.2" x 4.2"#8 JIC $202.77 / EACH

Usual lead time is 3 day(s).
Expedite available.
749400656 - 1456 GPM0.90 HP---9.8" x 7.2" x 4.2"#8 JIC $249.03 / EACH

Usual lead time is 3 day(s).
Expedite available.
749400956 - 1453 GPM0.85 HP---9.8" x 7.2" x 4.2"#8 JIC $218.19 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494012182 - 18420 GPM1.5 HP---12" x 12.6" x 4.2"#16 JIC $254.43 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494015182 - 1846 GPM1.46 HP---12" x 12.6" x 4.2"#8 JIC $254.43 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494018182 - 1844 GPM1.44 HP---12" x 12.6" x 4.2"#12 JIC $282.19 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494021213 - 21524 GPM2.85 HP---14.4" x 15" x 4.8"#16 JIC $316.88 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494024213 - 21512 GPM2.80 HP---14.4" x 15" x 4.8"#12 JIC $342.32 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494027213 - 2156 GPM2.70 HP---14.4" x 15" x 4.8"#12 JIC $340.78 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494030254 - 25624 GPM3.40 HP284 - 28624 GPM5.60 HP16.9" x 17.5" x 5.6"#16 JIC $424.05 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494033254 - 25612 GPM3.30 HP284 - 28612 GPM5.50 HP16.9" x 17.5" x 5.6"#12 JIC $413.26 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494036254 - 2566 GPM3.20 HP284 - 2866 GPM5.10 HP16.9" x 17.5" x 5.6"#12 JIC $426.36 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494039324 - 32636 GPM10.00 HP364 - 36536 GPM10.00 HP20.7" x 21.3" x 5.8"#20 JIC $633.76 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494042324 - 32612 GPM9.30 HP364 - 36512 GPM9.30 HP20.7" x 21.3" x 5.8"#16 JIC $636.85 / EACH

Usual lead time is 3 day(s).
Expedite available.
7494045324 - 3268 GPM7.20 HP364 - 3658 GPM8.80 HP20.7" x 21.3" x 5.8"#16 JIC $639.93 / EACH

Usual lead time is 3 day(s).
Expedite available.
Page 1 of 1
