LAKE FLOW METERS - BASIC INLINE, BI-DIRECTIONAL
- Flow meter is equipped for bi-directional flow operation.
- Ideal for accurately monitoring pump performance and media flows through hydraulic circuits.
- Select from aluminum, brass or stainless steel to meet system and media compatibility requirements.
- Allows the designer to install the meter in any orientation (horizontal, vertical or inverted).
- Weather-tight for use outdoors and/or on systems where wash downs are required.
- A sharp-edged stainless steel orifice provides excellent measurement for viscosities from 0-500 SSU.
- Designed as a hydraulic service tool, this meter will provide years of maintenance-free performance.
- Standard selection of NPT, SAE and BSP ports reduces the amount of adapters required for installation.
- Maximum Temperature: 240°F
- Made in the USA
- Catalog Pages
- Installation, Operation and Maintenance Manual
- Order Guide
| Image | Item # | Mfr. Number | Material | Ports | GPM Range | Fluid Media | Maximum PSI | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3830003 | B3A-6HS-05BI | Aluminum | 1/4" NPTF (Dry Seal) | 0.5 to 5 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830004 | B3A-6HS-10BI | Aluminum | 1/4" NPTF (Dry Seal) | 1 to 10 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830005 | B3A-6HS-15BI | Aluminum | 1/4" NPTF (Dry Seal) | 1 to 15 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830008 | B3A-6HA-05BI | Aluminum | 3/8" NPTF (Dry Seal) | 0.5 to 5 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830009 | B3A-6HA-10BI | Aluminum | 3/8" NPTF (Dry Seal) | 1 to 10 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830010 | B3A-6HA-15BI | Aluminum | 3/8" NPTF (Dry Seal) | 1 to 15 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830013 | B3A-6HB-05BI | Aluminum | 1/2" NPTF (Dry Seal) | 0.5 to 5 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830104 | B3S-7HT-10BI | Stainless Steel | 1/2" BSP (British Standard Pipe) | 1 to 10 GPM | Oil (0.873 Specific Gravity) | 6000 PSI | $695.45 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830015 | B3A-6HB-15BI | Aluminum | 1/2" NPTF (Dry Seal) | 1 to 15 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $311.66 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830018 | B3A-6HE-05BI | Aluminum | #6 SAE (O-Ring Seal) | 0.5 to 5 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830019 | B3A-6HE-10BI | Aluminum | #6 SAE (O-Ring Seal) | 1 to 10 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830020 | B3A-6HE-15BI | Aluminum | #6 SAE (O-Ring Seal) | 1 to 15 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830023 | B3A-6HF-05BI | Aluminum | #8 SAE (O-Ring Seal) | 0.5 to 5 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830024 | B3A-6HF-10BI | Aluminum | #8 SAE (O-Ring Seal) | 1 to 10 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $323.68 / EACH Usual lead time is 3 day(s). Expedite available. | |||
| 3830025 | B3A-6HF-15BI | Aluminum | #8 SAE (O-Ring Seal) | 1 to 15 GPM | Oil (0.873 Specific Gravity) | 3500 PSI | $311.66 / EACH Usual lead time is 3 day(s). Expedite available. |
