COOLING TOWER
- NEMA Premium Efficency
- 40°C Ambient Temperature Rating
- 36 Month Warranty from Purchase Date
- Moisture Resistant Stator Insulator Coating
- Drain provisions for All mounting positions
- Totally Enclosed Air OVer Enclosure (TEAO)
- All direction Conduit Box Drain provisions
- Dual Oversized Sealed Bearings
- Bearing Retainer Gaskets Installed
- Silicone Sealed End Bells
- 2 Part Eposy Top Coat Sealant
- Lead Sead Conduit Box Gasket
- Space Heaters Installed
- Tapped Shaft for Vertical Lifting
- Stainless Stell Hardware
- Inverter Rated - 1000:1 Variable Torque
- MG1 Part 31 Compliant for VFD use
- IP55 Protection
- 1045 Steel Shaft (thru 326T), 4140 (326T & up)
- Multi-mount Removable Feet through 326T
- One-Way Auto-purge Brass Condensation Drains
- 1.25 Service Factor to 50HP, 1.15 SF above 50 HP
- Conduit Box is 90° Rotatable
- Double Lip Shaft Seal on DE & ODE
- VPI Lap wound Stator with Tropicalization Coating
- Rubber Slinger on Shaft
- C & D Flanges Available upon request
- Available in TEFC enclosure upon request
- Class F Insulation System with Class H Stator
- F1, F2, F0 Field Convertible kup to 326T (Shipped F1)
- Class 1, Division 2, Groups A, B, C & D Certified
- EISA Compliant
| Image | Item # | MFR Number | HP | Frame | RPM | Voltage | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 5966037 | CT3-CI-TF-213T-4-B-D-7.5 | 7.5 | 213T | 1800 | 208-230/460 | $1,165.03 / EACH Usually ships in 1 day(s) | |||
| 5966045 | CT3-CI-TO-213T-4-B-D-7.5 | 7.5 | 213T | 1800 | 208-230/460 | $1,165.03 / EACH Usually ships in 1 day(s) | |||
| 5966038 | CT3-CI-TF-215T-4-B-D-10 | 10 | 215T | 1800 | 208-230/460 | $1,267.43 / EACH Usually ships in 1 day(s) | |||
| 5966046 | CT3-CI-TO-215T-4-B-D-10 | 10 | 215T | 1800 | 208-230/460 | $1,267.43 / EACH Usually ships in 1 day(s) | |||
| 5966039 | CT3-CI-TF-254T-4-B-D-15 | 15 | 254T | 1800 | 208-230/460 | $1,707.91 / EACH Usually ships in 1 day(s) | |||
| 5966047 | CT3-CI-TO-254T-4-B-D-15 | 15 | 254T | 1800 | 208-230/460 | $1,707.91 / EACH Usually ships in 1 day(s) | |||
| 5966040 | CT3-CI-TF-256T-4-B-D-20 | 20 | 256T | 1800 | 208-230/460 | $1,909.91 / EACH Usually ships in 1 day(s) | |||
| 5966048 | CT3-CI-TO-256T-4-B-D-20 | 20 | 256T | 1800 | 208-230/460 | $1,909.91 / EACH Usually ships in 1 day(s) | |||
| 5966041 | CT3-CI-TF-284T-4-B-D-25 | 25 | 284T | 1800 | 208-230/460 | $2,196.79 / EACH Usually ships in 1 day(s) | |||
| 5966049 | CT3-CI-TO-284T-4-B-D-25 | 25 | 284T | 1800 | 208-230/460 | $2,196.79 / EACH Usually ships in 1 day(s) | |||
| 5966042 | CT3-CI-TF-286T-4-B-D-30 | 30 | 286T | 1800 | 208-230/460 | $2,491.37 / EACH Usually ships in 1 day(s) | |||
| 5966050 | CT3-CI-TO-286T-4-B-D-30 | 30 | 286T | 1800 | 208-230/460 | $2,491.37 / EACH Usually ships in 1 day(s) | |||
| 5966043 | CT3-CI-TF-324T-4-B-D-40 | 40 | 324T | 1800 | 208-230/460 | $3,166.12 / EACH Usually ships in 1 day(s) | |||
| 5966051 | CT3-CI-TO-324T-4-B-D-40 | 40 | 324T | 1800 | 208-230/460 | $3,166.12 / EACH Usually ships in 1 day(s) | |||
| 5966044 | CT3-CI-TF-326T-4-B-D-50 | 50 | 326T | 1800 | 208-230/460 | $3,648.68 / EACH Usually ships in 1 day(s) |
