BOTTLE JACKS - MANUAL
- 12-50 Ton
- 10,000 PSI
- Hydraulic system is protected from internal damage by a by-pass mechanism
- Machined and polished cylinders with die-cut threads provide non-abrasive leak-free performance
- Fabricated from hard-cast steel with heat-treated critical stress areas
- Unique cross-type forged release valve assures positive load control
- Wide, rugged base provides stability and strength
- BVA Catalog
- **Indicates item alone does not meet factory minimum alone
| Image | Item # | BVA Model# | Capacity | Min Height | Max Height | Hydraulic Lifting | Extension Screw | Base Length | Base Width | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 8013061 | J10125** | 12 Ton | 9.5" | 18.6" | 6" | 3.1" | 5.3" | 5.1" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013064 | J10129** | 12 Ton | 6" | 10.6" | 3" | 1.6" | 5.3" | 5.1" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013067 | J10205 | 20 Ton | 9.5" | 18.6" | 6" | 3.1" | 6.3" | 5.9" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013070 | J10209 | 20 Ton | 6.5" | 11.3" | 3.1" | 1.6" | 6.3" | 5.9" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013405 | J10300 | 30 Ton | 11" | 18" | 7" | -0 | 8.1" | 6.9" | Add to cart to see price Usually ships in 1 day(s) |
