  • General Purpose
  • Spring Return
  • Chrome plated piston rod protects against corrosion and damage
  • Polyurethane U-Cup seals provide longer seal life
  • Solid one piece alloy steel body
  • One piece aluminum alloy bearing protects against cylinder wall damage
  • CH38F high flow coupler with dust cap is standard on most cylinders (*Unless Otherwise Specified, CRZ14F)
  • **Indicates cylinder is equipped with carrying handle
  • ISO 9001
  • Items Comply with ASME B30.1, ANSI B40.1, & SAE100 Industry Standards
  • Safety Practices: Good industry practice recommends not exceeding 80% of maximum rated capacities of all products
  • BVA 2016 Catalog
  • +Indicates item qualifies for prepaid freight (deducted on invoice)
*** Slide left / right to view more ***
ImageItem #BVA Model#Capacity (Tons)BoreStrokeRod Dia.Effective Area (in2)Oil Capacity (in3)Collapsed HeightExtended HeightPriceOrder Qty.
8013270H02032 Ton1"3.07"0.87"0.762.285.39"8.46" Add to cart to see price
Usually ships in 1 day(s)
8012801H0500*5 Ton1.18"0.63"0.98"1.10.691.63"2.26" Add to cart to see price
Usually ships in 1 day(s)
8012804H05015 Ton1.13"1"1"114.58"5.58" Add to cart to see price
Usually ships in 1 day(s)
8012807H05035 Ton1.13"3.07"1"13.076.65"9.72" Add to cart to see price
Usually ships in 1 day(s)
8012810H05055 Ton1.13"5.08"1"15.088.7"13.78" Add to cart to see price
Usually ships in 1 day(s)
8012813H05075 Ton1.13"7.09"1"17.0910.71"17.8" Add to cart to see price
Usually ships in 1 day(s)
8012816H05095 Ton1.13"9"1"19.0312.75"21.75" Add to cart to see price
Usually ships in 1 day(s)
8012827H100110 Ton1.69"0.98"1.49"2.242.193.62"4.6" Add to cart to see price
Usually ships in 1 day(s)
8012830H100210 Ton1.69"2.01"1.49"2.244.54.84"6.85" Add to cart to see price
Usually ships in 1 day(s)
8012833H100410 Ton1.69"4.02"1.49"2.2496.85"10.87" Add to cart to see price
Usually ships in 1 day(s)
8012836H100610 Ton1.69"5.94"1.49"2.2413.39.84"15.78" Add to cart to see price
Usually ships in 1 day(s)
8012839H100810 Ton1.69"7.95"1.49"2.2417.8111.85"19.8" Add to cart to see price
Usually ships in 1 day(s)
8012842H101010 Ton1.69"9.96"1.49"2.2422.3113.86"23.82" Add to cart to see price
Usually ships in 1 day(s)
8012845H101210 Ton1.69"11.97"1.49"2.2426.8115.87"27.84" Add to cart to see price
Usually ships in 1 day(s)
8012848H101410 Ton1.69"14.02"1.49"2.2431.417.72"31.74" Add to cart to see price
Usually ships in 1 day(s)
