  • Ideal for pulling machine
  • High quality
  • Single Acting
  • Spring Return
  • Removable threaded rod adapter allows for the use of a variety of threaded attachments
  • Used to attach accessories to rod end and base
  • Maximum Working Pressure: 10,000 PSI / 700 bar
  • CH38F High Flow Coupler & Dust Cap Standard
  • BVA 2016 Catalog
*** Slide left / right to view more ***
ImageItem #BVA Model#Capacity (Tons)BoreStrokeRod Dia.Effective Area (in2)Oil Capacity (in3)Collapsed HeightExtended HeightPriceOrder Qty.
8013340HT05055 Ton1.33"5.07"1.33"1.005.0010.31"15.39" Add to cart to see price
Usually ships in 1 day(s)
8012965HT100610 Ton1.49"5.95"1.49"2.2413.3311.46"17.41" Add to cart to see price
Usually ships in 1 day(s)
8012968HT101010 Ton1.49"9.96"1.49"2.2422.315.47"25.43" Add to cart to see price
Usually ships in 1 day(s)
8013341HT200520 Ton2.24"5.16"2.24"5.1425.711.77"16.93" Add to cart to see price
Usually ships in 1 day(s)
