  • High strength steel construction
  • One piece high grade alloy bearing for side load protection and longer life
  • Polyurethane cup seal helps provide for optimum performance
  • External rod threads
  • Internal base threads
  • Used for pulling and tensioning
  • Maximum Working Pressure: 10,000 PSI / 700 bar
  • BVA 2016 Catalog
*** Slide left / right to view more ***
ImageItem #BVA Model#Capacity (Tons)BoreStrokeRod Dia.Effective Area (in2)Oil Capacity (in3)Collapsed HeightExtended HeightPriceOrder Qty.
8012989HP02052.5 Ton1.13"5"0.75"0.562.7810.55"15.55" Add to cart to see price
Usually ships in 1 day(s)
8012992HP05055 Ton1.69"5.55"1.18"1.146.3411.93"17.48" Add to cart to see price
Usually ships in 1 day(s)
8012995HP100610 Ton2.17"5.95"1.26"2.4414.4811.75"17.7" Add to cart to see price
Usually ships in 1 day(s)
8012994HPB100610 Ton2.17"5.95"1.26"2.4414.4821.02"28.88" Add to cart to see price
Usually ships in 1 day(s)
8012996HPB1006A10 Ton2.17"5.95"1.26"2.4414.4822.24"28.17" Add to cart to see price
Usually ships in 1 day(s)
8012997HPB3006A+30 Ton3.35"6.1"6.3338.6342.72"48.82" Add to cart to see price
Usually ships in 1 day(s)
