Male Run Tee Swivel Inch Tube

Name: Trausch Dynamics
Address: 3727 Westgate Road, Grand Island, NE, 68803
Telephone: 800-323-5749

Fittings Model P7444 Pro-Fit Thread Male Run Tee Swivel
Use on compressed air
Operating pressure up to 250 PSI
-4° to +140°F temperature range
Body: Technopolymer (glass-reinforced Nylon 66 Resin); Insert: brass; collet: nickel-plated brass; seals: NBR
Use with Nylon 6, 11, or 12, polyethylene, PU (polyurethane recommended 90A durometer and above) Hytrel Polyester.
Tube Diameter OD: 5/32", 1/4", 5/16", 3/8", 1/2"
Thread Type: NPTF 1/8", 1/4", 5/16", 3/8", 1/2" with Pro-Fit reusable

*** Slide table left/right to view more ***

Item	Order Qty.	Fitting #	1 Tube OD	2 Tube OD
1033034 P7444 53-02 Camozzi \| 5/32" O.D. Tube X 5/32...	$4.58/each Usually ships in 5 days Min Order Qty: 10	P7444 53-02	5/32"	1/8"
1033035 P7444 53-04 Camozz \| 5/32" O.D. Tube X 5/32"...	$5.93/each Usually ships in 5 days Min Order Qty: 10	P7444 53-04	5/32"	1/4"
1033036 P7444 04-02 Camozzi \| 1/4" O.D. Tube X 1/4"...	$4.87/each Usually ships in 5 days Min Order Qty: 10	P7444 04-02	1/4"	1/8"
1033037 P7444 04-04 Camozzi \| 1/4" O.D. Tube X 1/4"...	$5.89/each Usually ships in 5 days Min Order Qty: 10	P7444 04-04	1/4"	1/4"
1033038 P7444 04-06 Camozzi \| 1/4" O.D. Tube X 1/4"...	$7.63/each Usually ships in 5 days Min Order Qty: 10	P7444 04-06	1/4"	3/8"
1033039 P7444 06-04 Camozzi \| 3/8" O.D. Tube X 3/8"...	$8.70/each Usually ships in 5 days Min Order Qty: 10	P7444 06-04	3/8"	1/4"
1033043 P7444 08-06 Camozzi \| 1/2" O.D. Tube X 1/2"...	$11.39/each Usually ships in 5 days Min Order Qty: 10	P7444 08-06	1/2"	3/8"

*** Slide table left/right to view more ***
