REDUCING MULTI TEE METRIC TUBE
- Fitting Model 7545 Reducing Multi Tee
- Use on compressed air
- Operating pressure up to 250 PSI
- -4° to +140°F temperature range
- Body: Technopolymer (glass-reinforced Nylon 66 Resin); Insert: brass; collet: nickel-plated brass; seals: NBR
- Use with Nylon 6, 11, or 12, polyethylene, PU (polyurethane recommended 90A durometer and above) Hytrel Polyester.
- Tube Diameter OD: 4, 6, 8, 10, 12, 16mm
| Image | Item # | Fitting # | 1 Tube OD | 2 Tube OD | 3 Tube OD | 4 Tube OD | 5 Tube OD | Price | Order Qty. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1033204 | 7545 6-4 | 6 mm | 4 mm | 4 mm | 4 mm | 6 mm | $11.12 / EACH Usually ships in 5 day(s) |
| ||||
| 1033205 | 7545 8-6 | 8 mm | 6 mm | 6 mm | 6 mm | 8 mm | $12.09 / EACH Usually ships in 5 day(s) |
| ||||
| 1033206 | 7545 10-8 | 10 mm | 8 mm | 8 mm | 8 mm | 10 mm | $17.53 / EACH Usually ships in 5 day(s) |
| ||||
