ROHRLEITUNG POPPET - SCREW TO CONNECT UNDER PRESSURE
"VR" Screw to Connect Under Pressure Coupling Series
Connection under residual pressure is allowed in one side
Robustness and ease of construction
Special valves ensure a good seal of the coupling disconnected and minimize spillage of fluid
Shape of internal parts is designed to reduce turbulence and pressure drop
External sleeve protects the sealing surface of the male body
Good resistance to pressure impulses
Compact design, Simple to use
Before coupling: clean the mating surface of the couplings to avoid dirt inclusion in the circuit
To connect insert the nipple in the coupler, screw the sleeve until positive stop (surface contact of two moving parts), do not push together the couplings, screw only
The use of tools for the second part of the connection can be necessary if there is high residual pressure in the circuit
Check inspection holes to ensure that the coupling is fully connected (no free space allowed)
To disconnect unscrew totally the sleeve from the nipple
