30, 40 & 80 GPM RELIEF VALVES
- Trausch Dynamics
- Intended for Use as a Pressure Limiting Device in a Hydraulic Circuit
- 30 GPM Maximum Valve: Differential Area Hydraulic Relief Valve, #12 SAE O-Ring Ports Pressure & Tank, #10 SAE O-Ring Gauge Port (Plugged), 3000 PSI Preset, 1500-3000 PSI Adjustment Range, Dimensions are 2.5" x 2.5" x 5.32"
- 40 GPM Maximum Valve: Pilot-Operated Spool-Type Hydraulic Relief Valve, #16 SAE O-Ring Ports Pressure & Tank, #6 SAE O-Ring Gauge Port (Plugged), 3000 PSI Preset, 300-3500 PSI Adjustment Range, Dimensions are 2.5" x 2.5" x 7.0"
- 80 GPM Maximum Valve: Pilot-Operated Spool-Type Hydraulic Relief Valve, #20 SAE O-Ring Ports Pressure & Tank, #6 SAE O-Ring Gauge Port (Plugged), 3000 PSI Preset, 1200-3500 PSI Adjustment Range, Dimensions are 3.0" x 3.0" x 8.625"
- Body Color is Silver
- Body Material is Aluminum
- Buna N Seals
- (2) 1/4-20 UNC Mounting Holes Located on Rear
- No Mounting Restrictions
| Image | Item # | Maximum GPM | Pressure & Tank Ports | Gauge Port | PSI Adjustment Range | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|
 | 9502247 | 30 GPM | #12 SAE O-Ring | #10 SAE O-Ring | 1500-3000 PSI | $155.59 / EACH Quantity breaks In stock - Ships same day | |||
 | 9502169 | 40 GPM | #16 SAE O-Ring | #6 SAE O-Ring | 500-3500 PSI | $166.74 / EACH Quantity breaks In stock - Ships same day | |||
 | 9502774 | 80 GPM | #20 SAE O-Ring | #6 SAE O-Ring | 1200-3500 PSI | $229.30 / EACH Quantity breaks In stock - Ships same day |
