Tipper Valves

Tipper Valves

  • High flow capacity to meet the requirements of large dump trucks or end dump trailers
  • Regulates flow and limits pressure, providing reliable performance in heavy-duty environments
  • Integral air shifter for use with reathering or on/off style controls (available separately)
  • 3-Way single acting function three position functions - Pressure (Raise) / Hold / Return (Lower)

*** Slide table left/right to view more ***

Item Order Qty. Main Relief Setting Air-Actuated Relief Setting Max Pressure Max Flow Rate Inlet Port
Single Acting Hydraulic Tipper Valve, 2000 PSI Main Relief Setting, 3500 PSI Max Pressure, 60 GPM Max Flow Rate, #16 JIC Inlet Port, #16 SAE O-Ring Cylinder and Tank Ports, 1/8" NPTF Air Ports

1270004

Single Acting Hydraulic Tipper Valve, 2000 P...

$695.66/each

In stock - Ships same day

2000 PSI N/A 3500 PSI 60 GPM (1) JIC -16
Single Acting Hydraulic Tipper Valve, Dual Pressure, 2000 PSI Main Relief Setting, Air-Actuated Relief Valve Setting is 3000 PSI, 3500 PSI Max Pressure, 60 GPM Max Flow Rate, #16 JIC Inlet Port, #16 SAE O-Ring Cylinder and Tank Ports, 1/8" NPTF Air Ports

1270005

Single Acting Hydraulic Tipper Valve, Dual P...

$758.54/each

In stock - Ships same day

2000 PSI 3000 PSI 3500 PSI 60 GPM (1) JIC -16

*** Slide table left/right to view more ***

Page 1 of 1
