CLOCKWISE ROTATION
- Direct Interchange for Vickers V10
- Balanced Vane Type
- Fixed Displacement
- Quieter operation than Gear Pump
- High Efficiency
- 100% Tested
- *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.
| Image | Item # | Mfr. Number | Rotation | in3 Per Rev. | GPM @ 1200 RPM | Max. PSI | Max. RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 6302921 | V101P1P11A20 | CW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302922 | V101P2P11A20 | CW | 0.4 | 2 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302923 | V101P3P11A20 | CW | 0.6 | 3 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302924 | V101P4P11A20 | CW | 0.8 | 4 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302925 | V101P5P11A20 | CW | 1 | 5 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302926 | V101P6P11A20 | CW | 1.19 | 6 GPM | 2200 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302927 | V101P7P11A20 | CW | 1.39 | 7 GPM | 2000 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet Opposite Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302928 | V101P1P11B20 | CW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302929 | V101P2P11B20 | CW | 0.4 | 2 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302930 | V101P3P11B20 | CW | 0.6 | 3 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302931 | V101P4P11B20 | CW | 0.8 | 4 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302932 | V101P5P11B20 | CW | 1 | 5 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302933 | V101P6P11B20 | CW | 1.19 | 6 GPM | 2200 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302934 | V101P7P11B20 | CW | 1.39 | 7 GPM | 2000 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet 90 Deg CCW from Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day | |||
 | 6302935 | V101P1P11C20 | CW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | 1/2" NPT | Outlet In Line with Inlet | 5/8-9 Splined Shaft | $242.43 / EACH Ships next business day |
