CLOCKWISE ROTATION
- Direct Interchange for Vickers V10
- Balanced Vane Type
- Fixed Displacement
- Quieter operation than Gear Pump
- High Efficiency
- 100% Tested
- *Not all vane pumps available are shown. Call and ask to speak to a sales represetative if the model you seek is not shown here.
| Image | Item # | Mfr. Number | Rotation | in3 Per Rev. | GPM @ 1200 RPM | Max. PSI | Max. RPM | Inlet | Outlet | Port Orientation | Shaft | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 6303081 | V101P1S1A20 | CW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303082 | V101P2S1A20 | CW | 0.4 | 2 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303083 | V101P3S1A20 | CW | 0.6 | 3 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303084 | V101P4S1A20 | CW | 0.8 | 4 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303085 | V101P5S1A20 | CW | 1 | 5 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303086 | V101P6S1A20 | CW | 1.19 | 6 GPM | 2200 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303087 | V101P7S1A20 | CW | 1.39 | 7 GPM | 2000 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet Opposite Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303088 | V101P1S1B20 | CW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303089 | V101P2S1B20 | CW | 0.4 | 2 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303090 | V101P3S1B20 | CW | 0.6 | 3 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303091 | V101P4S1B20 | CW | 0.8 | 4 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303092 | V101P5S1B20 | CW | 1 | 5 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303093 | V101P6S1B20 | CW | 1.19 | 6 GPM | 2200 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303094 | V101P7S1B20 | CW | 1.39 | 7 GPM | 2000 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet 90 Deg CCW from Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day | |||
 | 6303095 | V101P1S1C20 | CW | 0.2 | 1 GPM | 2500 PSI | 1800 RPM | 1" NPT | #08 SAE O-Ring | Outlet In Line with Inlet | 3/4" Dia x 3/16" Key x 1-3/4" Length Keyed Shaft | $242.43 / EACH Ships next business day |
