  • Liquid-filled industrial pressure gauges are available in bottom, center back, front or panel mount
  • Designed for use with gas, oil, and water or any medium not corrosive to brass or bronze
  • Recommended for reducing shock caused by pressure or vibration
  • Movement: Brass
  • Bourdon Tube: C-shaped in Copper Alloy up to 600 PSI and Helical in Phosphor Bronze above 600 PSI
  • Pointer:Black Enameled Aluminum
  • Dial: White Aluminum
  • Window: Temperature compensating polycarbonate
  • Case Material: 304 Stainless steel
  • Connection Material: Brass
  • Conenction Size: 1/4" Male NPT or #4 Male SAE
  • Accuracy: ASME / ANSI B40.1 Grade A (1-2%)
  • Fill Material: Glycerin
  • Wetted Parts: Copper Alloy
