SINGLE ACTING - HOLLOW HOLE, ALUMINUM
- Aluminum
- Up to 60% lighter than steel counterparts
- Ideal for pulling and pushing applications
- Heavy duty compression spring
- Dual wipers prevent contamination
- Collar thread protector
- High flow coupler with dust cap
- Safety Practices: Good industry practice recommends not exceeding 80% of maximum rated capacities of all products
- BVA Catalog
| Image | Item # | BVA Model# | Capacity (Tons) | Bore | Stroke | Effective Area (in2) | Oil Capacity (in3) | Collapsed Height | Extended Height | Price | Order Qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 8013525 | HUC3003 | 30 Ton | 2.84" | 3" | 7.21 | 22 | 8.68" | 11.68" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013526 | HUC3006 | 30 Ton | 2.84" | 6" | 7.21 | 44 | 11.68" | 17.68" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013527 | HUC6003 | 60 Ton | 4.08" | 3" | 12.3 | 37 | 10.25" | 13.25" | Add to cart to see price Usually ships in 1 day(s) | |||
 | 8013528 | HUC6006 | 60 Ton | 4.08" | 6" | 12.3 | 74 | 13.25" | 19.25" | Add to cart to see price Usually ships in 1 day(s) |
