Power Units |
|
Monarch power unit, 12 VDC
motor driving a gear pump, 1.4 GPM at 2000 psi, lever
operated 4 way spring centered valve is integral to unit,
1/4" NPTF ports. Runs a double acting cylinder or a
hydraulic motor. Hydraulic pump runs when the valve lever is
moved in either direction. 3 quart steel tank.
|
|
▼
Click HS number for price
HS
Nbr |
Mfgr
Nbr |
Size L x W x H |
Fig. |
Ship
Wt. |
|
6110032 |
M-310 |
18" x 7" x 13 1/2" |
A |
35 |
|
  |
|
Fig. A |
|
|
|
Monarch power unit, 12 VDC
motor driving a gear pump, 1.4 GPM at 2000 psi. Power unit
features (2) lever operated 4 way spring centered valves
integral to unit, 1/4" NPTF ports. This unit is ideal for
running (2) cylinders or (2) motors. Hydraulic pump runs
when valve lever is moved in either direction. 3 quart steel
tank with tabs for mounting.
|
▼
Click HS number for price
HS
Nbr |
Mfgr
Nbr |
Size
L x W x H |
Fig. |
Ship
Wt. |
|
6110034 |
M-300 |
22" x 6" x 15" |
B |
46 |
|
  |
|
Fig. B |
|
|
|
|
 |
|
 |
