PTO Gear Pumps |
|
 |
Prince Hydraulic Gear Pumps • PTO Models, 540 and
1000 RPM • Self adjusting wear plates on both sides of gears •
Center section available in high strength aluminum alloy
(standard), or high strength cast iron ("C" suffix) • Proper
size adapters are provided for inlet connections to hose • Set
relief valve (not provided with pump) at 2250 psi for all models
• Reservoir size should be at least equal in volume to pump
output per minute • 2 outlet ports are provided with NPT adapter
for one port and a plug to seal unused port. |
|
 |
|
Click HS number for price |
HS
Nbr |
Mfgr
Nbr |
Cubic in
per rev |
GPM @ RPM
@ 2000 psi |
RPM |
Ports |
Hose Sizes
Inlet x Outlet |
Suction Port
Thread |
Pressure
Port Thread |
PSI
Cont |
Ship
Wt. |
|
6100017 |
HC-PTO-1A |
9.9 |
21 |
540 |
side |
1 1/4" x 3/4" |
#16 SAE |
#12 SAE |
2000 |
40 |
|
6100585 |
HC-PTO-1AC |
9.9 |
21 |
540 |
side |
1 1/4" x 3/4" |
#16 SAE |
#12 SAE |
2000 |
54 |
|
6100034 |
HC-PTO-2A |
5.7 |
11.4 |
540 |
side |
1" x 1/2" |
#16 SAE |
#12 SAE |
2000 |
36 |
|
6100602 |
HC-PTO-2AC |
5.7 |
11.4 |
540 |
side |
1" x 1/2" |
#16 SAE |
#12 SAE |
2000 |
44 |
|
6100051 |
HC-PTO-3A |
5.7 |
22.4 |
1000 |
side |
1 1/4" x 3/4" |
#16 SAE |
#12 SAE |
2000 |
36 |
|
6100619 |
HC-PTO-3AC |
5.7 |
22.4 |
1000 |
side |
1 1/4" x 3/4" |
#16 SAE |
#12 SAE |
2000 |
44 |
|
6100068 |
HC-PTO-7A |
3.6 |
7.1 |
540 |
side |
1" x 1/2" |
#16 SAE |
#12 SAE |
2000 |
33 |
|
6100638 |
HC-PTO-8A |
3.6 |
13.5 |
1000 |
side |
1 1/4" x 3/4" |
#16 SAE |
#12 SAE |
2000 |
33 |
|
6100642 |
HC-PTO-8AC |
3.6 |
13.5 |
1000 |
side |
1 1/4" x 3/4" |
#16 SAE |
#12 SAE |
2000 |
42 |
|
6100019 |
HC-PTO-9A |
7.1 |
17.1 |
540 |
side |
1 1/4" x 3/4" |
#16 SAE |
#12 SAE |
2000 |
38 |
|
6100085 |
HC-P-K11 |
9.9 |
40 |
1000 |
rear |
2" x 1" |
#20 SAE |
#16 SAE |
2000 |
40 |
|
6100653 |
HC-P-K11C |
9.9 |
21 |
540 |
rear |
2" x 1" |
#20 SAE |
#16 SAE |
2000 |
54 |
|
|
|
 |
|
| Torque
