Directional Control Valves • Cartridges in Body


• Black Anodized Aluminum Block • 3000 PSI Maximum • All Ports are #6 SAE
• Can Be Used on Pressure and Tank DC and AC Power Units

Click HS number for price
HS
Nbr
Max
GPM
Circuit
Type
# of
Coils
Electrical
Connection

Fig.
Ship
Wt.
Hydraulic
Schematic
9501630 8 Closed Center 2 12 VDC Double Spade A 5
9501631 8 Closed Center 2 12VDC Wire Leads B 5
9501632 8 Closed Center 2 24 VDC Double Spade A 5
9501633 8 Closed Center 2 24VDC Wire Leads B 5
9501634 8 Closed Center 2 125VAC 1/2" Conduit C 5
9501640 8 Open Center 2 12 VDC Double Spade A 5
9501641 8 Open Center 2 12VDC Wire Leads B 5
9501642 8 Open Center 2 24 VDC Double Spade A 5
9501643 8 Open Center 2 24VDC Wire Leads B 5
9501644 8 Open Center 2 125VAC 1/2" Conduit C 5
9501650 8 Tandem Center 2 12 VDC Double Spade A 5
9501651 8 Tandem Center 2 12VDC Wire Leads B 5
9501652 8 Tandem Center 2 24 VDC Double Spade A 5
9501653 8 Tandem Center 2 24VDC Wire Leads B 5
9501654 8 Tandem Center 2 125VAC 1/2" Conduit C 5



  -B
P- -A
T-
    Fig. A



  -B
P- -A
T-
    Fig. B




  -B
P- -A
T-
    Fig. C
