Quick Couplers • Hydraulic
Flat Face • NPT Threads |
|
 |
• Interchange to Aeroquip FD89/FD49, Faster 2FFI,
Parker FE • Series FIRG: ISO 16028 Interchange • 3/8" Body Size
is HTMA (Hydraulic Tool Manufacturers Association).• 1/2" body
is very common on skid steer loaders |
 |
|
Click HS number for price |
HS
Nbr |
Similar to
Aeroquip® |
Body
Size |
Type |
Female
Thread |
Max
Pressure |
Max
Flow |
Ship
Wt. |
|
2317000 |
FD89-1001-04-04 |
1/4" |
Female Body |
1/4" Pipe |
4285 psi |
3 GPM |
0.6 |
|
2317050 |
FD89-1002-04-04 |
1/4" |
Male Tip |
1/4" Pipe |
4285 psi |
3 GPM |
0.4 |
|
2317009 |
FD49-1001-08-06 |
3/8" |
Female Body |
1/2" Pipe |
4285 psi |
6 GPM |
0.8 |
|
2317059 |
FD49-1002-08-06 |
3/8" |
Male Tip |
1/2" Pipe |
4285 psi |
6 GPM |
0.5 |
|
2317006 |
FD49-1001-06-06 |
3/8" |
Female Body |
3/8" Pipe |
4285 psi |
6 GPM |
0.9 |
|
2317056 |
FD49-1002-06-06 |
3/8" |
Male Tip |
3/8" Pipe |
4285 psi |
6 GPM |
0.5 |
|
2317012 |
FD89-1001-08-08 |
1/2" |
Female Body |
1/2" Pipe |
3570 psi |
12 GPM |
1.1 |
|
2317062 |
FD89-1002-08-08 |
1/2" |
Male Tip |
1/2" Pipe |
3570 psi |
12 GPM |
0.8 |
|
2317014 |
FD89-1001-12-08 |
1/2" |
Female Body |
3/4" Pipe |
3570 psi |
12 GPM |
1.2 |
|
2317063 |
FD89-1002-12-08 |
1/2" |
Male Tip |
3/4" Pipe |
3570 psi |
12 GPM |
0.8 |
|
2317018 |
FD89-1001-12-12 |
3/4" |
Female Body |
3/4" Pipe |
3570 psi |
26 GPM |
1.7 |
|
2317068 |
FD89-1002-12-12 |
3/4" |
Male Tip |
3/4" Pipe |
3570 psi |
26 GPM |
0.9 |
|
2317021 |
FD89-1001-16-16 |
1" |
Female Body |
1" Pipe |
3570 psi |
50 GPM |
2.1 |
|
2317071 |
FD89-1002-16-16 |
1" |
Male Tip |
1" Pipe |
3570 psi |
50 GPM |
1.2 |
Female Half
Male Half |
Protective Caps •
Hydraulic Flat Face |
|
Determine Body
Size |
| • Protective caps are useful
accessories which prevent dust, water, or mud from entering
the quick couplings and lengthen their lives • Material is
PVC/Rubber blend • Red in color |
|
|
|
|
|
Body Size |
OD |
|
1/4" |
0.635" |
|
3/8" |
0.780" |
|
1/2" |
0.970" |
|
3/4" |
1.063" |
|
1" |
1.179" |
|
 |
|
|
|
|
|
 |
|
 |
