Diagnostic Quick Coupler Tips |
|
 |
• Eaton Aeroquip • Quick Release Coupling for
Diagnosis • Steel Construction • Maximum operating pressure:
7,000 psi • Rated flow: 0.5 GPM • Interchangeable with Parker PD
Series. |
 |
|
▼
Click HS number for price |
HS
Nbr |
Mfg
Nbr |
Body
Size |
Type |
Thread
Size |
Ship
Wt. |
|
2312342 |
FD90-1034-02-04 |
1/4 |
Female |
1/8" Pipe |
.15 |
|
2312345 |
FD90-1034-04-04 |
1/4 |
Female |
1/4" Pipe |
.15 |
|
2312326 |
FD90-1012-02-04 |
1/4 |
Male |
1/8" Pipe |
.15 |
|
2312333 |
FD90-1012-04-04 |
1/4 |
Male |
1/4" Pipe |
.15 |
|
2312325 |
FD90-1044-03-04 |
1/4 |
Male |
#3 (3/8-24) O-ring |
.15 |
|
2312337 |
FD90-1044-04-04 |
1/4 |
Male |
#4 (7/16-20) O-ring |
.15 |
|
2312336 |
FD90-1044-05-04 |
1/4 |
Male |
#5 (1/2-20) O-ring |
.15 |
|
2312339 |
FD90-1044-06-04 |
1/4 |
Male |
#6 (9/16-18) O-ring |
.15 |
|
2312328 |
FD90-1046-06-04 |
1/4 |
Male |
M14x1.5 Metric |
.15 |
|
2312830 |
FD90-1040-04 |
1/4 |
Dust Cap |
|
0.05 |
Dust Cap
|
Diagnostic Quick Coupler Bodies |
 |
• Eaton Aeroquip • Quick Release Coupling for
Diagnosis • Steel Construction • Maximum operating pressure:
7,000 psi • Rated flow: 0.5 GPM • Interchangeable with Parker PD
Series. |
|
|
▼
Click HS number for price |
HS
Nbr |
Mfg
Nbr |
Body
Size |
Type |
Thread
Size |
Ship
Wt. |
|
2312324 |
FD90-1021-02-04 |
1/4 |
Female |
1/8" Pipe |
0.3 |
|
2312327 |
FD90-1021-04-04 |
1/4 |
Female |
1/4" Pipe |
0.3 |
|
2312329 |
FD90-1041-04-04 |
1/4 |
Female |
#4 O-ring |
0.3 |
|
